JIS ERW Steel Pipes
Looking for JIS ERW Steel Pipes in specific standards & size at Factory Rate?
We are manufacturer, exporter & suppliers of JIS ERW Steel Pipes and supply high quality JIS ERW Steel Pipes in both large and small quantities worldwide & offer you the best prices in the market. We have a team of experienced professionals with years of experience in manufacturing.
Content Link:
- • JIS ERW Steel Pipes Specification
- • JIS ERW Steel Pipes Usage
- • JIS ERW Steel Pipes Packaging & Shipping
- • JIS ERW Steel Pipes Price
- • Pressure and Temperature Ratings for JIS ERW Steel Pipes
- • Other Useful Info
- • Our Inventory
JIS ERW Steel Pipes Specification
JIS - Japanese Industrial Standard
Product Type: G3454 spiral welded pipe
Product Name: JIS G3454 spiral welded carbon steel pipe
JIS G3454 spiral welded carbon steel pipe (JIS - Japanese Industrial Standard)
Size: 21.3mm to 1219.2mm
Wall Thickness: 2-50mm
Length: max 12000mm
Standard: JIS G3454, JIS G3445, JIS G3452, JIS G3444
Grade: STPG370, STPG410, STKM13A, STKM14A, SGP, STK290, STK400, STK500
JIS - Japanese Industrial Standard
- JIS G3429
Steel grade:STH38, STH55, STH67
Application: Seamless Steel Tubes in High Pressure Gas Cylinder - JIS G3439
Steel grade: STO-G, STO-H, STO-J, STO-N, STO-C, STO-D, STO-E
Application: Seamless Steel Oil Well, Casing, Tubing and Drill Pipe - JIS G3441
Steel grade:SCr 420TK, SCM415TK, SCM418TK, SCM420TK, SCM430TK, SCM435TK, SCM440TK
Application：Alloy Steel Tubes for General Structural Purpose - JIS G3444
Steel grade: STK 30, STK 41, STK 50, STK 51, STK 55
Application: Carbon Steel Tubes for General Structural Purpose
Dimension Range: 21.7-1016.0 mm - JIS G3445
Steel grade: STKM11A,STKM12A, STKM12B, STKM12C, STKM13A, STKM13B, STKM13C, STKMI4A, STKM14B, STKM14C, STKM15A, STKM18C, STKM16A, STKM18C, STKM17A, STKM17C, STKM18A, STKM18B, STKM18C, STKM19A, STKM19C, STKM20A
Application: Carbon Steel Tubes for Machine Structural Purposes - JIS G3454
Steel grade: STPG 38, STPG 42
Application: Carbon Steel Pipes for Pressure Service
Dimension Range: 10.5-660.4 mm - JIS G3455
Steel grade: STS 38, STS 42, STS 49
Application: Carbon Steel Pipes for High Pressure Service
Dimension Range: 10.5-660.4 mm - JIS G3456
Steel grade: STPT 38, STPT 42, STPT 49
Application: Carbon Steel Pipes for High Temperature Service
Dimension Range:10.5-660.4 mm - JIS G3458
Steel grade:STPA 12, STPA 20, STPA 22, STPA 23, STPA 24, STPA 25, STPA 26
Application: Alloy Steel Pipes for Service
Dimension Range:10.5-660.4 mm - JIS G3460
Steel grade:STPL 39, STPL 46, STPL 70
Application: Steel Pipes for Low Temperature Service
Dimension Range:10.5-660.4 mm - JIS G3461
Steel grade:STB 35, STB 42, STB 52
Application: Carbon Steel Boiler and Heat Exchanger Tubes
Dimension Range:15.9-139.8 mm - JIS G3462
Steel grade: STBAl2, STBAM, STBA20, STBA22, STBA23, STBA24, STBA25, STEA26
Application：Alloy Steel Boiler and Heat Exchanger Tubes
Dimension Range: 15.9-139.8 mm - JIS G3464
Steel grade: STBL 39, STBL46, STBL 70
Application: Steel Heat Exchanger Tubes for Low Temperature Service
Dimension Range: 15.9-139.8 mm - JIS G3465
Steel grade: STM-055, STM-C65, STM-R60, STM-1170, STM-1180, STM-R85
Application: Seamless Steel Tubes for Drilling
Dimension Range: Casing: 43-142mm / Hollow Pipes: 34-180mm / Drilling:33.5-50mm - JIS G3467
Steel grade: STF 42, STFAl2, STFA22, STFA23, 5TFA24, STFA23, STFA26
Application:Steel Tubes for Fired Heater
Dimension Range:60.5-267.4mm
JIS G3454 : 1988 Carbon Steel Pipe for Pressure Service
| Material of Grade | Chemical Composition (%) | Mechanical Properties | ||||||
| C Max |
Si Max |
Mn Max |
P Max |
S Max |
Yield Strength N/mm2. |
Tensile Strength N/mm2. |
Elongation (%) |
|
| STPG 370 | 02.5 | 0.35 | 0.3-0.90 | 0.040 | 0.040 | 215 | 370 | 30 |
| STPG 410 | 0.30 | 0.35 | 0.30-1.00 | 0.040 | 0.040 | 245 | 410 | 25 |
| Nominal Size | Outside Diameter mm. |
Thickness mm. |
Weight (plain end) kg/m. |
Hydrostatic Test Pressure | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| mm. | in | Class 2 kgf/cm2. |
Class 3 kgf/cm2. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
|
|
|
|
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
JIS G3444 : 1994 Carbon Steel Pipe for General Structural Purposes
| Material of Grade | Chemical Composition (%) | Mechanical Properties | ||||||
| C Max |
Si Max |
Mn Max |
P Max |
S Max |
Yield Strength N/mm2. |
Tensile Strength N/mm2. |
Elongation % |
|
| STK 400 | 0.25 | - | - | 0.040 | 0.040 | 235 | 400 | 23 |
| STK 490 | 0.18 | 0.55 | 1.50 | 0.040 | 0.040 | 315 | 490 | 23 |
| Nominal Size | Outside Diameter mm. |
Thickness mm. |
Weight (plain end) kg/m. |
| mm. | |||
| 15 | 21.70 | 2.00 | 0.98 |
| 20 | 27.20 | 2.00 2.30 |
1.24 1.41 |
| 25 | 34.00 | 2.30 | 1.80 |
| 32 | 42.70 | 2.30 2.50 |
2.29 2.48 |
| 40 | 48.60 | 2.30 2.50 2.80 3.20 |
2.63 2.84 3.16 3.58 |
| 50 | 60.50 | 2.30 3.20 4.00 |
3.30 4.52 5.57 |
| 65 | 76.30 | 2.80 3.20 4.00 |
5.08 5.77 7.13 |
| 80 | 89.10 | 2.80 3.20 |
5.96 6.78 |
| 90 | 101.60 | 3.20 4.00 5.00 |
7.76 9.63 11.90 |
| 100 | 114.30 | 3.20 3.50 4.50 |
8.77 9.58 12.20 |
| 125 | 139.80 | 3.60 4.00 4.50 6.00 |
12.10 13.40 15.00 19.80 |
| 150 | 165.20 | 4.50 5.00 6.00 7.10 |
17.80 19.80 23.60 27.70 |
| 175 | 190.70 | 4.50 5.30 6.00 7.00 8.20 |
20.70 24.20 27.30 31.70 36.90 |
| 200 | 216.30 | 4.50 5.80 6.00 7.00 8.00 8.20 |
23.50 30.10 31.10 36.10 41.10 42.10 |
| 250 | 267.40 | 6.00 6.60 7.00 8.00 9.00 9.30 |
38.70 42.40 45.00 51.20 57.30 59.20 |
| 300 | 318.50 | 6.00 6.90 8.00 9.00 10.30 |
46.20 53.00 61.30 68.70 78.30 |
| 350 | 355.60 | 6.40 7.90 9.00 9.50 12.00 12.70 |
55.10 67.70 76.90 81.10 102.00 107.00 |
| 400 | 406.40 | 7.90 9.00 9.50 12.00 12.70 |
77.60 88.20 93.00 117.00 123.00 |
JIS ERW Steel Pipes Usage
Spiral welded pipe used for the oil and gas transmission, pipe pile & for industrial purpose.
JIS ERW Steel Pipes Packaging & Shipping
Packed JIS ERW Steel Pipes
Packed JIS ERW Steel Pipes
Plastic closes both ends, Hexagonal bundles maximum 2.000 kg with several steel strips, Two tags on each bundle, Wrapped in waterproof paper, PVC sleeve, and IN in sackcloth with several steel strips, Plastic caps.
Both ends of each crate will indicate the order no., heat no., dimensions, weight and bundles or as requested. We can also offer customized packaging for JIS ERW Steel Pipes as per customer's requirement.
Overseas Packaging
Export packaging is geared towards the protection, handling and transport of JIS ERW Steel Pipes by air or sea freight and, as such, shares many characteristics with export and transport packaging. Utmost care must also be taken to make overseas packaging suitable for long periods of storage. It is important for overseas packaging to be designed with ease of handling in mind, so as to ensure JIS ERW Steel Pipes is treated with the utmost care at all times.
JIS ERW Steel Pipes Price
JIS G3454 spiral welded carbon steel pipe
FOB Price: 1500/Ton
Pressure and Temperature Ratings for JIS ERW Steel Pipes
Other Useful Info
What is JIS?
Japanese Industrial Standards (JIS) specifies the standards used for industrial activities in Japan. The standardization process is coordinated by Japanese Industrial Standards Committee and published through Japanese Standards Association.
JIS for seamless pipes
JIS G3429, JIS G3439, JIS G3441, JIS G3444, JIS G3445
JIS G3454, JIS G3455, JIS G3456, JIS G3458, JIS G3460
JIS G3461, JIS G3462, JIS G3464, JIS G3465, JIS G3467
